Product Description
Application:
The driving cable has the characteristics of cold resistance, softness, wear resistance, and oil resistance. It is suitable for connecting cables for mobile electrical appliances with special requirements for cold resistance and oil resistance at AC rated voltages of 0.6/1KV and below. This product has been widely used in metallurgy, electric power, Shipbuilding, automobile manufacturing and other industries.
Cable characteristics:
It has excellent electrical insulation, good ozone resistance, humidity resistance, heat resistance, cold resistance, and aging resistance.
It has the stability of oxygen resistance, ozone resistance and partial discharge stability. It also has excellent cold resistance. Even at -50°C, it still maintains good flexibility.
Has excellent weathering resistance and light stability. In particular, it is halogen-free and has flame-retardant properties. The ethylene-propylene rubber insulated cable with chlorosulfonated polyethylene sheath is suitable for places where flame-retardant is required.
It has good water resistance and good softness, so it is more suitable for laying on mines and ships.
Technical parameter:
| No. | Description | Material | Dimension |
| 1 | Phase conductor | Flexible tinned copper, class5 | 3C*70sqmm |
| 2 | Conductor cores | copper | 3 cores |
| 3 | Conductor shield | Semi-conductive rubber | Min. 0.3 |
| 4 | Insulation | EPR | 2.2mm |
| 5 | Screen | Tinned copper wires braiding | 3*35/3 |
| 6 | Metal shield | Braiding copper wire with cotton thread | Coverage>60% |
| 7 | Control cores | With tinned copper conductor and al foil screen | 2*(2*1.5) |
| 9 | Control cores insulation | Thermosetting ethylene propylene rubber | 0.9mm |
| 10 | Control cores sheath | CPE | 1.0mm |
| 11 | Filler | Ruber | / |
| 12 | Outer sheath | CPE | 5.5mm |
| 13 | Approx. Cable dia. | / | 77mm |
| 14 | Cable weight per meter | / | 10.1kg |
Packaging & Shipping
Packing Material: Coil (For small size & short length) , Wooden Drum , Iron-Wooden Drum , Steel Drum
Shipping: Loading port from Qingdao or Shanghai , 12-24 hours from facotry to sea port
